Built for professionals who demand efficiency, durability, and organization, our enclosed spray truck keeps your equipment protected and your workflow streamlined. Every detail is designed to help you work smarter, whether you’re treating trees, landscapes, or commercial properties.
150″ Enclosed Spray Truck
- Designed to fit the Isuzu NPR HD with a 109″ wheelbase chassis.
- 150″ fully enclosed aluminum painted white body with product storage, 5 roll up doors, amber strobe lights, and rear back-up camera
- 500-gallon stainless steel mix tank (300/200 split tank)
- 50-gallon poly mix tank
- 1500 Series Hannay hose reel w/roller guide and pin lock
- 400′ x 3/8″ 800 psi spray hose
- 300′ x ½” 800 psi spray hose
- 2″ fill lines with air gap
- Color-coded stainless steel manifold system
- Mixing/eductor tank mounted on deck with Handwash
- Central electric box with protective breakers
- 500-watt power inverter
- Honda GX390 13 HP engine
- Delta 100 VA diaphragm pump 26 gpm
- 21″ Udor spray gun w/ wall mount holders
- JD-9 pistol spray gun w/ wall mount holder
- Extra holders for root feeder tool
- 5-gallon auxiliary fuel tank for Honda engine
180″ Enclosed Spray Truck
- Designed to fit the Isuzu NRR Class 5 with a 132″ wheelbase chassis.
- 180″ fully enclosed aluminum painted white body with product storage, 5 roll up doors, amber strobe lights, and rear back-up camera
- 700-gallon stainless steel tank (300/400 split)
- 100-gallon poly mix tank
- 1500 Series Hannay hose reel w/roller guide and pin lock
- 400′ x 3/8″ 800 psi spray hose
- 300′ x ½” 800 psi spray hose
- 2″ fill lines with air gap
- Color-coded stainless steel manifold system
- Mixing/eductor tank mounted on deck with Handwash
- Central electric box with protective breakers
- 500-watt power inverter
- Honda GX390 13 HP engine
- Delta 100 VA diaphragm pump 26 gpm
- 21″ Udor spray gun w/ wall mount holders
- JD-9 pistol spray gun w/ wall mount holder
- Extra holders for root feeder tool
- 5-gallon auxiliary fuel tank for Honda engine
Additional Options
- Rear-mounted hitch
- Driver-side hose reel
- Jet agitation (Udor turbo nozzle) can be added to any tank
Many features on this truck can be customized to meet your specific operational needs. We would be happy to discuss the available options and configure the truck to best fit your application.
BeeLine Equipment does not provide the chassis. However, we can connect you with a trusted dealer to help streamline the purchasing process and make the experience as simple as possible.
